qualified hex cap screw a453 gr.660 din 1.4980 alloy

Nr.25-Incoloy a286 kuuskantpoldid 1.4980 a286 kinnitusdetailid gh2132 roostevabast terasest riistvara masinakruvide kinnitused

GH2132 /A286 EN1.4980 stainless steel fastenr DIN931 half thread hex bolt M36*260mm

MATERIAL NO :1.4980

UNS NO:S66286

DESIGNATION: ALLOY 286

Mehaanilised omadused
Tihedus			8,5 kg / dm³
Rm min			930 N / mm²				Rm max				1180 N / mm²
Rp 0,2 min			630 N / mm²				Rp 0,2 max				850 N / mm²
Pikendus min			12 %				Pikkus max				20 %
Keemiline koostis (massiprotsentides)
Element	C	Ni		Kr	Mn	Lk		S	Mo	Al		Ti	V	B
min	0.03	24		13.5	1				1			1.9	0.1	0.003
max	0.08	27		16.5	2	0.025		0.015	1.5	0.35		2.3	0.5	0.01

Kiirdetailid

Päritolukoht: Jiangsu, Hiina (Mandri)
Brand Name: QFC
Mudelinumber: DIN933
Standard: DIN
Incoloy a286: hex bolts
1.4980: ASTM A453 660
High Quality Stainless Steel A286: Hex nuts
Flange nuts: Socket cap head screws
hardware: a286 fasteners
a286 fasteners: UNS S66286
